700 to 3000MHz Coaxial Isolator TG3232XS SMA Type
700 to 3000MHz Coaxial Isolator Order Examples
700 to 3000MHz Coaxial Isolator Connector Type
|
SMA Type Connector Options |
N Type Connector Options |
||||
|
Port 1 |
Port 2 |
Abbreviation |
Port 1 |
Port 2 |
Abbreviation |
|
SMA-F |
SMA-F |
S |
N-F |
N- |
N |
|
SMA-F |
SMA-M |
SKJ |
N- |
N-M |
NKJ |
|
SMA- |
SMA-F |
SJK |
N-M |
N-F |
NJK |
|
SMA-M |
SMA-M |
SJ |
N-M |
N-M |
NJ |
700 to 3000MHz Coaxial Isolator Basic Specifications
| Impedance | 50 Ω |
| Connector Type | SMA-F |
| Size(mm) | 32.0*32.0*15.0 |
| Operating Temp | -30~+75℃/-45~+85℃ |
| Storage temperature | -50~+90 ℃ |
700 to 3000MHz Coaxial Isolator Specifications
|
Model No. (X=1: →Clockwise) (X=2: ←Anticlockwise) |
Freq. Range MHz |
IL. dB (max) |
Isolation dB (min) |
VSWR |
Forward Power CW |
Reverse Power W |
|
TG3232XS-X/700-900MHz |
700-900 |
0.60 |
18.0 |
1.3 |
100 |
20/100 |
|
TG3232XS-X/800-1000MHz |
800-1000 |
0.50 |
18.0 |
1.3 |
100 |
20/100 |
|
TG3232XS-X/920-960MHz |
920-960 |
0.30 |
23.0 |
1.20 |
100 |
20/100 |
|
TG3232XS-X/960-1215MHz |
960-1215 |
0.40 |
18.0 |
1.3 |
100 |
20/100 |
|
TG3232XS-X/1028-1032MHz |
1028-1032 |
0.30 |
25.0 |
1.15 |
100 |
20/100 |
|
TG3232XS-X/1700-2200MHz |
1700-2200 |
0.40 |
20.0 |
1.25 |
100 |
20/100 |
|
TG3232XS-X/1700-2300MHz |
1700-2300 |
0.50 |
18.0 |
1.30 |
100 |
20/100 |
|
TG3232XS-X/1800-2200MHz |
1800-2200 |
0.40 |
20.0 |
1.25 |
100 |
20/100 |
|
TG3232XS-X/2200-2700MHz |
2200-2700 |
0.50 |
19.0 |
1.25 |
100 |
20/100 |
Reverse power 100W size diagram
The reflected power of this figure is 100W, the indicators are shown in the table above, and its model is TG3232XS-X-100/XXX-XXXMHz
Instructions:
1, the isolator connector can be selected SMA male and female head, can be used with the user;
2, the reflection power is commonly used 20W and 100W options, you can also configure the total reflection power according to user requirements;
3, only some common frequencies in the table, can be produced according to the user's requirements;
4, if you do not find what you are looking for, please contact us!
